2013 JLG 450AJ SERIES 2

The 2013 JLG 450AJ Series 2 is a reliable used articulating boom lift designed for versatility and efficiency in aerial work applications. We have thoroughly inspected this unit, performing a comprehensive service to ensure it is ready to tackle your tasks effectively. With 2,170 operational hours, this boom lift is in good condition and offers dependable performance for various projects. Its articulating boom design allows for enhanced maneuverability, making it ideal for hard-to-reach areas. This model is popular for its durability and ease of use, suitable for both industrial and construction environments. If you are in need of a boom lift that combines functionality with precision, the JLG 450AJ Series 2 is a solid choice.

JLG 450AJ Series II — Dual Fuel Specifications

Performance

• Platform Height: 45 ft (13.72 m)
• Horizontal Outreach: 25 ft (7.62 m)
• Up and Over Clearance: 24 ft 8 in (7.52 m)
• Platform Capacity: 500 lb (227 kg)
• Swing (Continuous): 360° Non-Continuous
• Platform Rotation: 180° Hydraulic
• Jib Length: 4 ft 1 in (1.24 m)
• Jib Range of Articulation: +70° / –55°

Powertrain

• Engine (Dual Fuel): GM Vortec 3000 MPFI — 82 hp (61 kW)
• Fuel Type: Gasoline / LPG (Dual Fuel)
• Fuel Tank Capacity: 16 gal (60 L)
• Drive Speed (4WD): 4.5 mph (7.2 km/h)
• Gradeability (4WD): 45 %
• Axle Oscillation: 4 in (10 cm)

Hydraulic System

• System Capacity: 38 gal (144 L)
• Hydraulic Tank: 36 gal (136 L)

Chassis

• Tires: 12 × 16.5 Foam-Filled Rough Terrain
• Brakes: Hydraulic Disc
• Drive: 4 × 4 All-Wheel Drive
• Steering: 2-Wheel, Front

Dimensions

• Overall Height: 7 ft 5 in (2.26 m)
• Overall Width: 6 ft 10 in (2.08 m)
• Overall Length: 21 ft 6 in (6.55 m)
• Ground Clearance: 1 ft (0.30 m)
• Wheelbase: 6 ft 7 in (2.01 m)

Platform

• Platform Size: 30 × 72 in (0.76 × 1.83 m)
• Platform Entry: Side Entry with Swing Gate

Weights

• Machine Weight (Dual Fuel 4WD): ~12,650 lb (5,738 kg)

Operational

• Turning Radius (Inside): 6 ft 7 in (2.01 m)
• Turning Radius (Outside): 14 ft 7 in (4.45 m)
• Swing Type: Non-Continuous (355° ± 5°)
